Erection of Isolator Checklist

Civil Plinth work is done properly as per Isolator Manufacturers instruction.

Yes	No	N/A

Foundation bolts of Isolator is of Correct size shown in drawing.

Yes	No	N/A

Specified manufacture isolator used
.

Yes	No	N/A

Isolator correct size (amps) received on site.

Yes	No	N/A

Isolator mounted at the correct height.
.

Yes	No	N/A

Terminal pad connected tightened properly.

Yes	No	N/A

Isolator mounted within suitable distance & line of sight of connected appliance.

Yes	No	N/A

Suitable isolator mounting structure is used.

Yes	No	N/A

Isolator mounting structure is tightened properly

Yes	No	N/A

Isolator mounting structure Hot Dip quality checked properly

Yes	No	N/A

Isolator Operation mechanism quality checked properly
.

Yes	No	N/A

Isolator Earth blade assembly checked properly.
.

Yes	No	N/A

No holes drilled in isolator enclosure to effect the IP rating of the isolator

Yes	No	N/A

Suitable cable gland used & checked for tightness.

Yes	No	N/A

All connected cable cores checked for tightness & without any copper strands showing.

Yes	No	N/A

Verify that the earth cable conduct is connected straight through the isolator.

Yes	No	N/A

Verify the fixed contact and moving contact is aligned properly .

Yes	No	N/A

Check functionally of the isolator ON/OFF by Mechanical Endurance.

Yes	No	N/A

Check isolator is labelled.

Yes	No	N/A

Does the Testing of CRM is conducted on isolator.

Yes	No	N/A

Mechanical operation testing is conducted on isolator.

Yes	No	N/A

Isolator locked properly after charging.

Yes	No	N/A
